# PWM

{% tabs %}
{% tab title="1" %}

<figure><img src="/files/zp4MuPatlTJYWjmVor7x" alt=""><figcaption></figcaption></figure>
{% endtab %}

{% tab title="2" %}

<figure><img src="/files/i7x2iKxIjnEQobz1hAVq" alt=""><figcaption></figcaption></figure>
{% endtab %}

{% tab title="3" %}

<figure><img src="/files/73f8JSUWqdAvjTjYQVh6" alt=""><figcaption></figcaption></figure>
{% endtab %}

{% tab title="4" %}

<figure><img src="/files/WxX4jKJjYJ4e9QrHpUMD" alt=""><figcaption></figcaption></figure>
{% endtab %}

{% tab title="5" %}

<figure><img src="/files/73f8JSUWqdAvjTjYQVh6" alt=""><figcaption></figcaption></figure>
{% endtab %}

{% tab title="6" %}

<figure><img src="/files/i7x2iKxIjnEQobz1hAVq" alt=""><figcaption></figcaption></figure>
{% endtab %}

{% tab title="7" %}

<figure><img src="/files/zp4MuPatlTJYWjmVor7x" alt=""><figcaption></figcaption></figure>
{% endtab %}
{% endtabs %}

## Code

```python
"""
PWM Demo Code
Breadstick Innovations
April 26, 2024
https://learn.breadstick.ca/breadstick/breadsticks/raspberry-breadstick/code-examples/pwm

duty_cycle is a 16-bit integer
2^16 = 65536 values
0 is one of those values,
so the range is 0-65535.

range(start,stop,step)
range(0,10,1) = 0,1,2,3,4,5,6,7,8,9
range(10,0,-1) = 10,9,8,7,6,5,4,3,2,1
"""

from board import *
from pwmio import PWMOut
from time import sleep

led_5 = PWMOut(D5, frequency=500, duty_cycle=0)

while True:
    for i in range(0,65535,100):
        led_5.duty_cycle = i
        sleep(0.001)
    for i in range(65535,0,-100):
        led_5.duty_cycle = i
        sleep(0.001)
```
